• Expands to Relational Database Service
  • Traditional relational databases that include tables, rows, fields
  • On-Line Transaction Processing (OLTP) type DB
  • You can copy a snapshot to another region if you want to have your database available in another region
  • You scale your DB by taking a snapshot and doing a restore to a larger sized tier
  • Eliminates much of relational database management
  • Can be scaled independently
    • CPU
    • memory
    • storage
    • IOPS
  • AWS manages
    • backups
    • software patching
    • automatic failure detection
    • recovery
  • Can trigger, manual or automated backups
  • It provides high availability with primary instance which if fails, switch to secondary instance
  • Has a soft limit of 40 Amazon RDS DB instances per account
  • From 40, up to 10 can be Oracle or Microsoft SQL Server DB instances under the License Included model.
  • Customers can Bring Your Own License (BYOL) model to have all 40 DB instances for Oracle or Microsoft SQL Server
  • Supports database engines
    • MySQL
    • MariaDB
    • PostgreSQL
    • Oracle
    • Microsoft SQL Server
    • MySQL-compatible Amazon Aurora
    • AWS IAM controls AWS resources access to Amazon RDS databases.
  • For security
    • put database in an Amazon Virtual Private Cloud (Amazon VPC)
    • using Secure Sockets Layer (SSL) for data in transit
    • Using encryption for data at rest
  • RDS APIs and the AWS Management Console provide a management interface that allows you to create, delete, modify, and terminate RDS DB instances; to create DB snapshots; and to perform point-in-time restores
  • There is no AWS data API for Amazon RDS.
  • Once a database is created, RDS provides a DNS endpoint for the database which can be used to connect to the database.
  • Endpoint does not change over the lifetime of the instance even during the failover in case of Multi-AZ configuration
  • RDS leverages Amazon EBS volumes as its data store
  • RDS provides database backups, which are replicated across multiple AZ’s
  • RDS Multi AZ’s feature synchronously replicate data between a primary RDS DB instance and a standby instance in another Availability Zone, which prevents data loss,
  • RDS provides a DNS endpoint and in case of an failure on the primary, it automatically fails over to the standby instance
  • RDS also allows Read replicas for the supported databases, which are replicated asynchronously
  • RDS Provisioned IOPS, where the IOPS can be specified when the instance is launched and is guaranteed over the life of the instance

AWS RDS limits per region

ResourceDefault Limit
Cross-region snapshots copy requests5
DB Instances40
Event subscriptions20
Manual snapshots100
Option groups20
Parameter groups50
Read replicas per master5
Reserved instances40
Rules per DB security group20
Rules per VPC security group50 inbound 50 outbound
DB Security groups25
VPC Security groups5
Subnet groups50
Subnets per subnet group20
Tags per resource50
Total storage for all DB instances100 TiB
